TA RED SDR 11
With standard outlet spigots
T-piece TA RED SDR 11 with reduced spigot
- Gas, water and H2
- Working pressure: MOP (gas) 10 bar, PFA (water) 16 bar
- Material: PE 100
- Reduced spigots
- Safety technology
- DVGW test mark: DV-8601AU2248, DV-8606AU2249 and DV-8611AU2250
Areas of Application
The FRIALEN reduced TA red pieces are used for pipe outlets of HD-PE pipelines.
Assembly Instructions
The fusion of the pipe ends with the FRIALEN TA red takes place by FRIALEN-fusing – leakproof and longitudinally strong.
The pipe ends are prepared (removing the oxide layer/cleaning) according to the general installation instructions (see “Assembly Instructions” for “FRIALEN-Safety Fittings for house connections and distribution pipes up to d 225”).
Good reasons for using the FRIALEN TA red:
- Optimised size and flow conditions for branches
- Spigot outlet for maximum flexibility in pipework construction
- Large insertion depths - no retaining clamps necessary
- Open wire design for a secure and high-quality connection
- Long outlets - double length allows for double fusion on pipe diameters up to 63 mm
- Maximum stability thanks to large wall thicknesses
- Traceability coding Additional barcode for component traceability
