Shaft lining adapter for prefabricated concrete sewage inspection chambers

Shaft lining adapter for prefabricated concrete sewage inspection chambers ASF

  • Connecting element between concrete prefabricated manhole and sewage insert sleeve AEM
  • Reversed anchoring webs (T-section) on the entire circumferential width always ensure a firm and tight fit in the concrete
  • Defined internal surface and fitting ratio for reliable system seal with AEM
  • Stable internal diameter due to large wall thickness
  • Flush closure (inside and outside) in the concrete shaft sub-section according to DIN 4034
Go back Data sheet

PE 100

Maximum permissible test pressure 0.5 bar to DIN EN 1610

SKU d1 Pipe Diameter product.detail.attribute.Rohrdurchmesser D L Weight kg BX PU
680401 134 110 110 200 135 1,600 12 96
680402 190 160 160 250 135 1,900 8 64
680403 218 180 180 280 135 2,300 6 48
680404 250 200 200 315 135 2,700 4 32
680405 280 225 250 225 250 355 135 3,700 4 32
680407 316 280 280 400 135 4,800 4 32
680408 357 315 315 450 135 6,200 1 18
680409 402 355 355 500 135 7,400 1 18
680410 452 400 400 560 135 9,300 1 12
680411 502 450 450 630 135 12,700 3 6
680414 562 500 500 670 135 11,300 3 6
680412 628 560 560 710 135 8,800 3 6
680413 713 630 630 800 135 10,700 3 6

Note: If pipe dimensions ≥ d 710 are used, then please contact our hotline 0621/486-1896.

Sewage pipe systems are high-value assets of a value which has to be maintained for a long time. Increasing demands on the public sewage system require materials which meet these criteria. HDPE sewage pipes have been fused for many years with the FRIAFIT HDPE sewage system tightly, frictionlocked and root-proof.

Areas of Application

The FRIAFIT-Sewage Inspection Chamber Adapter ASF is the joining element between concrete inspection

chamber according to DIN 4034 and the FRIAFIT-Sewage Insert Sleeve AEM.

Assembly Instructions

The ASF is usually fitted in at the concrete works during manufacture of the inspection chambers. Application

of the ASF is possible even on local concrete inspection chambers.

The ASF Sewage Inspection Chamber Adapter is installed according to the general installation requirements (see also “Fitting Instructions” of the FRIAFIT-Sewage System).

Good reasons for using the FRIAFIT-Sewage Inspection Chamber Adapter ASF

  • The ASF is a corrosion resistant HDPE construction part

  • Stable internal diameter due to big wall thickness

  • Anchoring ribs twisted at the rear across the entire width ensure proper and leakfree anchoring in the concrete

  • Width of component and connection HDPE/concrete correspond to DIN 4034

  • Defined internal area for the reliable system sealing (AEM)

  • For subsequent installation in bricks chambers a longer version ASFL (L = 250 mm) was developed
