FRIAMAT basic eco

Fusion unit without documentation function

Powerful universal fusion unit FRIAMAT basic eco

  • State-of-the-art toroidal transformer technology with active cooling
  • Bright colour TFT display
  • With mini-scanner, reader wand or 1D/2D scanner (2D barcodes according to ISO 12176-5)
  • Extra long fusion cable (4 m)
  • Extra long power cable (5 m)
  • Weight approx. 18.0 kg

Note:

Possibility of updating the FRIAMAT software via the USB interface by the user.

Go back Data sheet
Fusion unit without documentation function
SKU Design Weight kg
611120 With mini scanner 18,000
613120 With reader wand 18,000
614120 With 1D/2D scanner 18,000

Technical details 1)

FRIAMAT basic eco 2)

Unit type

Universal fusion unit without documentation function

Model with mini scanner

Order no. 611120

Model with reader wand

Order no. 613120

Model with 1D/2D scanner

Order no. 614120

Maximum diameter

up to d 1200 3)

Input voltage range

AC 190 V - 250 V

Frequency range

44 Hz ... 66 Hz

Input current

AC 16 A max.

Output

3,5 kW

Unit fuse

16 A slow acting

Fusion voltage

8 - 48 V

Output currend

max. 110 A

Fusion current monitor

Short circuit and interruption

Barcode type

Code 2/5 interleaved;

2D code (QR; Aztec; Data Matrix) according to ISO 12176-5

Documentation of fusion data

no

Manual barcode emergency entry

yes

FRIAMAT preCHECK function

yes

Remote Start-/Stop pass

optional (order no. 624003)

Working temperature range

-20 °C ... +50 °C

Languages

23

Connecting cable

5 m with shaped plug

Fusion cable

4 m with fitting connector, 4 mm diameter

Weight

approx. 18 kg

Measurements W x D x H

260 x 500 x 340 mm

Housing

IP 54 / Protection class I

Approval / Quality

CE, ISO 9001, WEEE-Reg.-No. DE 49130851, RoHS, REACH

Accessory

Operating manual, transport box

1) Subject to technical modifications.

2) From year of construction (Q2/2021)

3) With the FRIAMAT basic eco, FRIALEN and FRIAFIT safety fittings up to d 900 can be fused in the entire working temperature range from -20 °C to +50 °C.

Utilising processing fittings from other manufacturers is possible even up to d 1200 and possibly larger. However, the specific power requirement of the fitting at the prevailing processing temperature must always be clarified beforehand with the fitting manufacturer.

  • High performance due to innovative toroidal transformer technology with flow-optimized, active cooling.
  • High-resolution, extremely bright 4.3 "TFT color display.
  • With mini-scanner, reader wand or new 1D/2D scanner for reading 2D barcodes according to ISO 12176-5. Adapter bag, language selection, adjustable buzzer volume, manual emergency entry. Extra-long power cable (4 m) and extra-long fusion cable (5 m). Weight approx 18 kg.
  • Continuous monitoring of the entire fusion process and all device functions.
  • With FRIAMAT preCHECK function: The most advanced way to fuse with foresight. The FRIAMAT automatically determines whether the next fusion can be performed completely to the end.
  • The user himself can install software updates via USB interface.
