FRIAMAT 7 basic

Universal fusion unit without documentation function

Powerful electrofusion unit with state-of-the-art converter technology and flow-optimized, active cooling.

High-resolution, extremely bright 4.3 “TFT color display.

The user himself can install software updates via USB interface.

With mini-scanner, reader wand or new 1D/2D scanner (2D barcodes according to ISO 12176-5), Adapter bag, language selection, adjustable buzzer volume, manual emergency entry. Extra-long power cable (4 m) and extra-long fusion cable (5 m). Weight approx 12,8 kg.

The tool is delivered in a transport box.

Go back Data sheet
Universal fusion unit without documentation function
SKU Design Weight kg
611130 with mini-scanner 12,800
613130 with reader wand 12,800
614130 with 1D/2D-scanner 12,800

Technical details 1)

FRIAMAT 7 basic

Type

Universal fusion unit without documentation function

Model with mini scanner

Order no. 611130

Model with reader wand

Order no. 613130

Model with 1D/2D scanner

Order no. 614130

Maximum diameter

To d 1200 2)

Input voltage range

AC 190 V – 250 V

Frequency range

44 Hz … 66 Hz

Input current

AC 16 A max.

Output

3,5 kW

Unit fuse

16 A slow acting

Fusion voltage

8 – 48 V

Output current

max. 110 A

Fusion current monitor

Short circuit and open circuit

Barcode type

1D: Code 2/5 interleaved

2D-Code (QR; Aztec; Data Matrix) nach ISO 12176-5

Interface

USB

Documentation of fusion and traceability data

No

Data memory

-

Log format

-

Manual barcode emergency entry

Yes

FRIAMAT preCheck

Yes

Software update via USB port

Yes

Operator pass

No

Supervisor pass

No

Working temperature range

-20 °C ... +50 °C

Languages

23

Power cable

5 m with shaped plug

Fusion cable

4 m with fitting connector, 4 mm diameter

Weight

approx. 12,8 kg

Dimensions

260 x 500 x 340 mm

Housing

Enclosure rating IP 54 / Protection class I

Approval / Quality

CE, ISO 9001, WEEE Reg. No. DE 49130851, RoHS

Accessory

Operating instructions, transport box

1) Specifications subject to change.

2) With FRIAMAT 7 basic, FRIALEN and FRIAFIT safety fittings up to d 900 can be fused in the entire working temperature range from -20 °C to +50 °C.

Use to process fittings from other manufacturers, even up to d 1200 and possibly larger, is fundamentally possible. However, the specific power requirement of the fitting at the prevailing processing temperature must first be clarified with the fitting manufacturer.

  • Powerful electrofusion unit with state-of-the-art converter technology and flow-optimized, active cooling.
  • High-resolution, extremely bright 4.3 “TFT color display.
  • With mini-scanner, reader wand or new 1D/2D scanner for reading 2D barcodes according to ISO 12176-5, Adapter bag, language selection, adjustable buzzer volume, manual emergency entry. Extra-long power cable (4 m) and extra-long fusion cable (5 m). Weight approx 12,8 kg.
  • Continuous monitoring of the entire fusion process and all device functions.
  • With FRIAMAT preCHECK function: The most advanced way to fuse with foresight. The FRIAMAT automatically determines whether the next fusion can be performed completely to the end.
  • The user himself can install software updates via USB interface.
