| Artikel | PN | D | E | F | G | L1 | L2 | Z1 | Z2 | Gewicht [kg] | VE |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1RBO325C00 | 16 | 25 | 52 | 1 1/4" | 3/4" | 19 | 16 | 3 | 13 | 0,070 | 200 |
| 1RBO332D00 | 16 | 32 | 59 | 1 1/2" | 1" | 22 | 19 | 3 | 13 | 0,070 | 200 |
| 1RBO340E00 | 16 | 40 | 72 | 2" | 1 1/4" | 26 | 21 | 3 | 17 | 0,160 | 80 |
| 1RBO363G00 | 16 | 63 | 96 | 2 3/4" | 2" | 38 | 26 | 3 | 30 | 0,410 | 30 |
| 1RBO375H00L | 10 | 75 | 120 | 3 1/2" | 2 1/2" | 45 | 30 | 3 | 33 | 0,620 | 15 |
| 1RBO390I00L | 10 | 90 | 135 | 4" | 3" | 53 | 33 | 5 | 37 | 0,810 | 12 |
