21.300.4X | VVOV

EPDM 21.300.40

  • Anschluss: Losflansch aus PVC-U, PN 10
  • Manschetten aus PE, O-Ringe aus EPDM oder Manschetten aus PTFE, O-Ringe aus FKM
  • Einbaulage beliebig
Zurück Datenblatt

Dichtung: EPDM

Artikel d PN A max B max C Gewicht [kg] VE
121300040020 20 16 146 124 60 0,300 1
121300040025 25 16 166 146 60 0,460 1
121300040032 32 16 191 173 70 0,660 1
121300040040 40 10 219 195 85 1,030 1
121300040050 50 10 249 222 105 1,390 1
121300040063 63 10 302 269 130 2,160 1
