Druckanbohrventile mit extra langem Abgangsstutzen und Schnellspannhebel RED SNAP
Kompaktbauteil aus PE-HD ohne Schraubverbindung. Betätigungsspindel aus Edelstahl 1.4305. Kein Nachisolieren notwendig. Leckage- und spanfreie Anbohrung bis 10 bar (Gas) bzw. 16 bar (Wasser). Integrierter Bohrer mit oberem und unterem Anschlag, geführt in metallischer Hülse. Max. 9 Umdrehungen für Öffnen/Schließen.
Werkzeugfreie Montage durch innovativen Schnellspannmechanismus (RED SNAP). Durch das neue Design werden 50 % der gesamten Installationszeit eingespart.
Mit freiliegendem Heizelement zur optimalen Wärmeübertragung. Wartungsfreies, mit Gestänge (z.B. FRIALEN DBS (EBS)) betätigbares Betriebsabsperrventil. Länge des Abgangsstutzen für 2 Schweißungen bemessen. Vierkant SW 14.
PE 100 SDR 11
Maximal zulässiger Betriebsdruck 16 bar (Wasser)/10 bar (Gas)
| Artikel | d1 | d2 | VE | PE | L | t2 | z1 | z2 | z3 | B1 | B2 | SW | Anbohr Ø da |
Umdr. Auf/Zu |
Gewicht kg/St. |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 | 617024 | 50 | 32 | 16.0 | 288 | 177.0 | 86.0 | 56 | 125.0 | 8.0 | 95.0 | 136.0 | 12.0 | 30 | 7.0 | 1.06 |
| 5 | 617025 | 63 | 32 | 16.0 | 288 | 177.0 | 86.0 | 63 | 125.0 | 10.0 | 108.0 | 146.0 | 12.0 | 30 | 7.0 | 1.1 |
| 1, 5 | 617026 | 63 | 40 | 12.0 | 216 | 177.0 | 115.0 | 63 | 155.0 | 10.0 | 108.0 | 146.0 | 12.0 | 30 | 7.0 | 1.43 |
| 5 | 616952 | 63 | 63 | 12.0 | 216 | 177.0 | 115.0 | 63 | 155.0 | 10.0 | 108.0 | 146.0 | 12.0 | 30 | 7.0 | 1.21 |
| 5 | 617027 | 75 | 32 | 12.0 | 216 | 177.0 | 86.0 | 69 | 125.0 | 10.0 | 120.0 | 146.0 | 12.0 | 30 | 7.0 | 1.12 |
| 4 | 616960 | 90 | 32 | 12.0 | 96 | 183.0 | 86.0 | 76 | 125.0 | 10.0 | 137.0 | 170.0 | 12.0 | 30 | 8.0 | 1.23 |
| 4 | 616961 | 90 | 40 | 12.0 | 96 | 183.0 | 92.0 | 76 | 130.0 | 10.0 | 137.0 | 170.0 | 12.0 | 30 | 8.0 | 1.24 |
| 4 | 616962 | 90 | 50 | 12.0 | 96 | 183.0 | 104.0 | 76 | 145.0 | 10.0 | 137.0 | 170.0 | 12.0 | 30 | 8.0 | 1.28 |
| 4 | 616963 | 90 | 63 | 12.0 | 96 | 183.0 | 115.0 | 76 | 165.0 | 10.0 | 137.0 | 170.0 | 12.0 | 30 | 8.0 | 1.35 |
| 616964 | 110 | 32 | 12.0 | 96 | 183.0 | 86.0 | 86 | 125.0 | 10.0 | 152.0 | 170.0 | 12.0 | 30 | 8.0 | 1.229 | |
| 616965 | 110 | 40 | 12.0 | 96 | 183.0 | 92.0 | 86 | 130.0 | 10.0 | 152.0 | 170.0 | 12.0 | 30 | 8.0 | 1.239 | |
| 616966 | 110 | 50 | 12.0 | 96 | 183.0 | 104.0 | 86 | 150.0 | 10.0 | 152.0 | 170.0 | 12.0 | 30 | 8.0 | 1.284 | |
| 616967 | 110 | 63 | 12.0 | 96 | 183.0 | 115.0 | 86 | 170.0 | 10.0 | 152.0 | 170.0 | 12.0 | 30 | 8.0 | 1.356 | |
| 4 | 616968 | 125 | 32 | 10.0 | 80 | 183.0 | 86.0 | 94 | 125.0 | 10.0 | 167.0 | 170.0 | 12.0 | 30 | 8.0 | 1.27 |
| 4 | 616969 | 125 | 40 | 10.0 | 80 | 183.0 | 92.0 | 94 | 135.0 | 10.0 | 167.0 | 170.0 | 12.0 | 30 | 8.0 | 1.28 |
| 4 | 616970 | 125 | 50 | 10.0 | 80 | 183.0 | 104.0 | 94 | 155.0 | 10.0 | 167.0 | 170.0 | 12.0 | 30 | 8.0 | 1.33 |
| 4 | 616971 | 125 | 63 | 10.0 | 80 | 183.0 | 115.0 | 94 | 170.0 | 10.0 | 167.0 | 170.0 | 12.0 | 30 | 8.0 | 1.4 |
| 4 | 616972 | 140 | 32 | 10.0 | 80 | 183.0 | 86.0 | 101 | 125.0 | 10.0 | 170.0 | 170.0 | 12.0 | 30 | 9.0 | 1.3 |
| 4 | 616973 | 140 | 63 | 10.0 | 80 | 183.0 | 115.0 | 101 | 175.0 | 10.0 | 170.0 | 170.0 | 12.0 | 30 | 9.0 | 1.43 |
| 2 | 616974 | 160 | 32 | 6.0 | 48 | 208.0 | 86.0 | 111 | 130.0 | 10.0 | 195.0 | 186.0 | 12.0 | 30 | 9.0 | 1.44 |
| 2 | 616975 | 160 | 40 | 6.0 | 48 | 208.0 | 92.0 | 111 | 140.0 | 10.0 | 195.0 | 186.0 | 12.0 | 30 | 9.0 | 1.45 |
| 2 | 616976 | 160 | 50 | 6.0 | 48 | 208.0 | 104.0 | 111 | 160.0 | 10.0 | 195.0 | 186.0 | 12.0 | 30 | 9.0 | 1.49 |
| 2 | 616977 | 160 | 63 | 6.0 | 48 | 208.0 | 115.0 | 111 | 180.0 | 10.0 | 195.0 | 186.0 | 12.0 | 30 | 9.0 | 1.57 |
| 3 | 616978 | 180 | 32 | 5.0 | 40 | 208.0 | 86.0 | 121 | 130.0 | 10.0 | 203.0 | 186.0 | 12.0 | 30 | 9.0 | 1.44 |
| 3 | 616979 | 180 | 40 | 5.0 | 40 | 208.0 | 92.0 | 121 | 145.0 | 10.0 | 203.0 | 186.0 | 12.0 | 30 | 9.0 | 1.45 |
| 3 | 616980 | 180 | 50 | 5.0 | 40 | 208.0 | 104.0 | 121 | 165.0 | 10.0 | 203.0 | 186.0 | 12.0 | 30 | 9.0 | 1.5 |
| 3 | 616981 | 180 | 63 | 5.0 | 40 | 208.0 | 115.0 | 121 | 180.0 | 10.0 | 203.0 | 186.0 | 12.0 | 30 | 9.0 | 1.57 |
| 3 | 616982 | 200 | 32 | 5.0 | 40 | 208.0 | 86.0 | 131 | 130.0 | 10.0 | 205.0 | 186.0 | 12.0 | 30 | 9.0 | 1.45 |
| 3 | 616984 | 200 | 63 | 5.0 | 40 | 208.0 | 115.0 | 131 | 185.0 | 10.0 | 205.0 | 186.0 | 12.0 | 30 | 9.0 | 1.59 |
| 2 | 616985 | 225 | 32 | 5.0 | 40 | 208.0 | 86.0 | 144 | 135.0 | 10.0 | 214.0 | 186.0 | 12.0 | 30 | 9.0 | 1.47 |
| 2 | 616986 | 225 | 40 | 5.0 | 40 | 208.0 | 92.0 | 144 | 150.0 | 10.0 | 214.0 | 186.0 | 12.0 | 30 | 9.0 | 1.49 |
| 2 | 616987 | 225 | 50 | 5.0 | 40 | 208.0 | 104.0 | 144 | 170.0 | 10.0 | 214.0 | 186.0 | 12.0 | 30 | 9.0 | 1.54 |
| 2 | 616988 | 225 | 63 | 5.0 | 40 | 208.0 | 115.0 | 144 | 190.0 | 10.0 |
